Our millwork shop drawings services cater to architects, custom furniture manufacturers and cabinet makers for manufacturing and assembly of wooden and metal furniture.

With 25+ years of experience and excellent craftsmanship in delivering architectural millwork drafting services; we create custom millwork detail drawings using AutoCAD as per the contractors and manufacturing tooling capacity. Our draftsmen provide highest quality of shop drawings, assembly & installation drawings and fabrication drawings for solid surface, stone / particle board, laminates, MDF, stone/Corian drawings, metals, alloys and much more.

Explore our work: Joinery Shop Drawings from Architectural Plans for Office Floor, UK

We partner with contractors, carpenters & woodworkers, sheet metal furniture manufacturers, and homeowners to understand their requirements and deliver millwork drawings as per American Woodworking Institute (AWI), NBKA, and NFC standards. Our teams of 150+ CAD professionals help navigating your fabrication contractors by developing production ready drawings using architectural plans. We also develop key plans from architectural plans including sections, elevations and scheduling of hardware installation.

Our skills for millwork drafting encompass:

  • Custom wood paneling design & drafting
  • Commercial and residential cabinet designs
  • Retail store fixtures and display furniture
  • Redlines drawings with installation notes
  • Custom kitchen cabinet drawings
  • Offices, hotels and restaurants furniture drafting
  • Production drawings & submittal drawings
  • Digital Signage, terracotta walls and glazing
  • DXF and CNC ready files for custom millwork

Millwork & Casework Shop Drawings from Architectural Plans of Museum, USA

View Case Study

Our CAD drafting teams deliver the best quality millwork shop drawings for high-end bespoke furniture industry use. Our reach to our clients across USA, UK, Canada, Australia, and Europe has experienced our CAD experts’ dedication to minimize errors and eliminated guesswork to remove design bottle necks.

Speak to our AutoCAD experts for millwork shop drawings for all your important projects.
