BIM LOD 300 Modeling of a Public Park as per AIA Standards, USA

Project Information
Client Profile
Construction Firm
California, USA
Infrastructure Construction
PDF Files, Hand Drawn Conceptual Sketches
BIM LOD 300 models of architecture, structural and MEP disciplines
Autodesk Revit & Navisworks
BIM Modeling
Client Challenges
  • Leveraging complete BIM capabilities to make the project efficient and economical.
  • Eliminating inter-disciplinary clashes before the actual construction.
  • Adding creativity to give architectural designs an excellent look while staying within timelines.

Business Needs

A construction firm from USA approached Hitech to develop a BIM LOD 300 model for a public park with excellent creativity of architectural designs.

Our Solutions and Approach

Our BIM teams embarked on the project to create the required 3D model based on the IFC drawings shared by the client.

  • Initial work started by integrating drawings and PDF files of all disciplines into one single model in Revit.
  • This was followed by all the interdisciplinary clashes being detected using Autodesk Navisworks and eliminating errors with an alternate design.
  • Keeping the architectural designs and aesthetics of the design in center, we developed the 3D BIM model as per AIA standards and shared it with the client six weeks later.

Business Impact

The 3D BIM model provided to the client proved beneficial in mitigating the reworks and potential waste of construction material due to the eliminated clashes. The client was able to plan in a structured way and save on any negative cash flow. The coordinated BIM model that was sent to the client ensured the quality of scheduling and designing as well as the safety in managing public-business infrastructure. It also helped the client to expect accurate quantities of floor paving and other equipment in terms of BOQ/BOM.

BIM Modeling Public Park
3D Model of Public Park
3D BIM for Public Park
3D Rendering Model Revit
3D Rendered Image
3D Modeling Services
